CNC-150 High-Speed ??Circular Sawing Machine

電影和電視 2026_2_28 10_18_20.png

The CNC-150 Inclined-Push Circular Sawing Machine primarily consists of the machine bed, power head assembly, feeding system,

clamping device, automatic feeder, material support rack, hydraulic system, electrical system, spray cooling system, automatic saw

blade lubrication system, saw blade cleaning device, and other components.

Process Flow:

The operator uses a crane to load multiple material bars onto the storage rack, laying them flat upon the loading platform supports.

A material-indexing mechanism then transfers the bars to the front conveyor frame, after which a lifting system feeds them sequentially

onto the feed roller conveyor. Finally, the main sawing unit cuts the material into finished products according to the pre-set fixed lengths.

Our company has already established two successful case studies within the Qingdao anchor chain industry: Qingdao Anchor Chain and

Wancheng Anchor Chain. The machinery at Qingdao Anchor Chain has been operating smoothly for approximately three years, while the

equipment at Wancheng Anchor Chain has been in normal operation for about two and a half years. Furthermore, the service life of the

saw blades used for cutting anchor chain steel has consistently remained stable within the range of 45 to 52 square meters. At Qingdao

Anchor Chain, the service life of blades used for cutting R3/R4 grade mooring chain steel also remains stable at approximately 25 square

meters.

Key Technical Parameters and Configuration

name	unit	Specification
Sawing Range	mm	○70-150 □ 60—105
Carbide Circular Saw Blade	mm	Φ460xφ50x2.7
Spindle Motor	Kw	15 (Spindle Servo) 15 Drive
Spindle Speed	Rp	30-110
Cut-off Feed Method		AC Servo Motor + Ball Screw + Linear Roller Guide
Main Clamping Method		Hydraulic Type I: One set each of vertical and horizontal clamping units.
Saw Blade Debris Removal Device		Passive Voice
Gear Backlash Compensation Device		Magnetic Powder Brake
Feed Drive Method		AC Servo Motor + Precision Gear and Rack
Feed Servo Motor	Kw	1.8
Feeding Clamp Method		Hydraulic Type I: Horizontal Clamping
Feeding Servo Motor	Kw	1.8
Material Lead-End Removal Length	mm	≥12（The program allows for the option to skip cutting the lead-in material.）
Remaining Length at the End	mm	≥15
Single-Feed Cutting Length	mm	10-2000（齒輪齒條+精密減速機）
Allowable Material Length	mm	5000-7000
Hydraulic Motor	Kw	3.75
Hydraulic Oil Capacity	L	Approximately 100
Machine tool weight: approx.	Kg	Approximately5800
Land Area	m	10.5 (Length) x 3.5 (Width)
